VA Series
2451 – 4855 | 1,830 – 13,164 kW
High-power reduction gearboxes without clutch — engineered for controllable-pitch propeller (CPP) applications and large diesel-mechanical propulsion in commercial workboats, dredgers, and offshore vessels.
Engineered for Controllable-Pitch Propulsion
The REINTJES VA series delivers up to 13,000 kW of high-torque reduction in a clutchless single-reduction package — the REINTJES standard for CPP-driven workboats, dredgers, and offshore vessels.
CPP-Optimized Design
Reduction gearbox without clutch — engineered for controllable-pitch propellers where reverse thrust is handled by propeller pitch, not the gearbox.
High Torque Density
Up to 13,164 kW continuous duty at 1,200 rpm in the VA 4855 — helical gears, case-hardened and tooth-flank ground, fabricated steel housing.
Two Standard Ratios per Model
Each VA model is published with two factory-standard reduction ratios — matching propeller selection to engine characteristics without custom tooling.
Continuous-Duty Reliability
Pressure-fed lubrication, integrated propeller thrust bearing, and seawater-resistant heat exchanger built for unlimited-hours commercial operation.
Specifying a CPP Propulsion Package?
Our application engineers help spec VA installations for controllable-pitch propeller drivetrains
Contact Our Sales Team TodayContinuous Duty
The VA series is rated exclusively for continuous-duty applications in large commercial displacement vessels.
Continuous Duty
Specifications
VA Reduction Gearbox
| Model | Weight Dry | Standard Reduction Ratio | kW/rpm |
|---|
kW/rpm values shown are Continuous Duty ratings per the REINTJES Product Guide 2026, listed for each standard reduction ratio. Reduction gearbox without clutch — designed for CPP propulsion. Custom ratios and input speed variations available upon request.
Versions
- Fabricated steel housing
- Helical gears, case-hardened and tooth-flank ground
- Reduction gearbox without clutch — for CPP applications
- Full power transmission in single output direction
- Integrated propeller thrust bearing
- Roller or plain bearing design
- Built-on seawater-resistant heat exchanger
- Maximum cooling water inlet temperature 32°C (90°F)
- Connection for remote pressure / temperature supervision
- Coated with synthetic resin varnish, RAL 7001 silver-grey
Downloads
REINTJES VA Series Brochure
VA 2451 - 4855 brochure with ratings, reduction ratios, weights, standard equipment, and options for large reduction gearbox applications.
Download PDFREINTJES Product Guide 2026
Complete REINTJES marine gearbox product guide.
