Steerprop W
About SteerProp W
The Steerprop W propulsors are tailormade to meet the most stringent customer needs. The Steerprop W azimuth propulsors utilize the latest technologies in hydrodynamics and power trains so that our customers can meet and exceed the required performance levels of today’s operating environments.
The Steerprop W employs carefully selected manufacturing methods to fulfill the latest requirements and improve design flexibility with modularization and scalability. Every vessel has its own performance requirements, and thanks to the modular design, customers can select various configurations to match their specific needs.
AT A GLANCE
- Power range from 900 to 9,000 kW
- Z-drive or integrated permanent magnet motor drive
- Available with open and ducted propeller
- Also available in shallow draft versions
- Steerprop Care condition monitoring included as standard
- Applications: offshore vessels, tugs, workboats, anchor handlers, ice-classed vessels
MAIN BENEFITS
- Increased overall performance
- The modular and flexible design enables various configurations
- Ducted propeller provide highest bollard pull / DP thrust
- High efficiency nozzle for improved free running efficiency
- High hydrodynamic efficiency
- Mechanically robust and simplified construction
Model Range & Specifications
The W Series comes in two drive options - a Z-drive or an integrated permanent magnet (LM) motor - both covering a power range of 900 to 9,000 kW, and both available in shallow-draft versions. Every unit ships with Steerprop Care condition monitoring as standard.
Features & Main Benefits
Modularity & Flexibility
- Adapts to different operations with mechanical, hybrid or electrical configurations.
- New improved nozzle design enhances performance.
- Available for tough ice classes.
- Enables higher input speeds, so you can use new high-speed engines that comply with Tier 4 environmental regulations.
High Hydrodynamic Efficiency
- Exceptional for its class, thanks to the optimized housing shape.
- No sacrificial anodes on the nozzle - instead, an added hydrodynamically shaped anode reduces flow separation from the nozzle's outer surface.
- High-efficiency nozzles for increased bollard pull.
Robust, Simplified Construction
- Electrical turning gear as standard.
- Lower body of cast steel for better hydrodynamic performance and high durability.
- All auxiliaries are built as modular units and tested during FAT.
Model Range
| Model | Max Power | Input Speed | Bollard Pull (2 units) | Propeller Dia. Ducted Std. | Dry Weight Z-Drive | Dry Weight LM | Max Ice Class Open | Max Ice Class Ducted |
|---|---|---|---|---|---|---|---|---|
| SP 10 W | 900 kW | 1000 - 2000 rpm | 29 MT | 1.6 m | 7 t | 10 t | None | None |
| SP 14 W | 1,250 kW | 750 - 2000 rpm | 41 MT | 1.9 m | 10 t | 14 t | None | None |
| SP 20 W | 1,650 kW | 750 - 2000 rpm | 54 MT | 2.2 m | 14 t | 18 t | ICE-1B | ICE-1B |
| SP 25 W | 2,000 kW | 750 - 2000 rpm | 65 MT | 2.4 m | 19 t | 23 t | ICE-1B | ICE-1B |
| SP 30 W | 2,250 kW | 750 - 2000 rpm | 75 MT | 2.6 m | 22.3 t | 30 t | ICE-1B | ICE-1B |
| SP 35 W | 2,525 kW | 750 - 2000 rpm | 85 MT | 2.8 m | 26 t | 37 t | ICE-1A | ICE-1A |
| SP 40 W | 3,000 kW | 750 - 1900 rpm | 100 MT | 3.0 m | 34 t | 42 t | ICE-1A Super | ICE-1A Super |
| SP 45 W | 3,500 kW | 900 - 1200 rpm | 115 MT | 3.2 m | 38 t | 47 t | ICE-1A Super | ICE-1A Super |
| SP 50 W | 4,500 kW | 750 - 1200 rpm | 148 MT | 3.6 m | 42 t | 53 t | ICE-1A Super | ICE-1A |
Prime Mover
Steering Type
Lubrication
Installation
Other input speeds available on request. The impact of propeller diameter on power, and of ice class on power, is confirmed case by case. The table covers units up to 4,500 kW; units above that - up to 9,000 kW with a maximum propeller diameter of 5.5 m - are engineered to specific project requirements. Specifications are per the Steerprop product booklet and subject to change without notice. For unit selection, contact Karl Senner.
